Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
CHH2200H2X
CHH2200H2X is a 200A, 2-pole bolt-on circuit breaker designed for reliable protection in commercial and industrial power distribution systems.This Cutler Hammer breaker features a robust CCH frame and is engineered for use with 37MM and 37SS three-phase modular metering stacks. The breaker provides thermal magnetic protection and is suitable for tenant main applications.
- Amperage Rating: 200A
- Voltage Rating: 120/240V
- Number of Poles: 2
- Mounting Type: Bolt-On
- Interrupt Rating: 25kAIC
- Frame Type: CCH
- Series: CHH
- Product Type: Tenant Main Breaker
- Connection: Bolt-On
- Certification: UL 489
Specifications
- Part Number: CHH2200H2X
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : CHH Series
- Type : CHH
- Voltage : 240
- Amperage : 200
- Phase : 1
- Poles : 2
- AIC rating : 25kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 782113032092
- GTIN : 00782113032092
- Dimensions : 4.5 in x 9.1 in x 5.3 in (Length/Depth x Height x Width)
- Weight : 4.4
- Certification : UL
