CCV2200X - Cutler Hammer CCV 200A 120/240V 2-Pole Tenant Main Circuit Breaker 10kAIC

Save $712.93
SKU: CCV2200X-New
Condition: New
Price:
$521.73 $1,234.66
Stock:
Low inventory, please call for stock check
Factory Lead Time: 69 business days. Ships based on manufacturer availability when out of stock. All factory-ordered products are non-cancelable and non-returnable.

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

CCV2200X - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
CCV2200X - Essential Electric Supply

Description

CCV2200X


CCV2200X is a Cutler Hammer CCV series 200A 120/240V 2-pole tenant main circuit breaker with a 10kAIC interrupt rating, designed for use in Type ECC unit enclosures. This breaker features a thermal/magnetic trip unit, load side terminals, and is suitable for #2/0 AWG to 300 kcmil copper or aluminum wire. It is UL 489 certified and built for reliable main circuit protection in commercial and residential applications.
  • Part Number: CCV2200X
  • Manufacturer: Cutler Hammer
  • Amperage Rating: 200 A
  • Voltage Rating: 120/240 VAC
  • Number of Poles: 2
  • Interrupt Rating: 10 kAIC
  • Series/Frame: CCV
  • Mounting Type: Bolt-On (Type ECC Unit Enclosures)
  • Wire Size: #2/0 AWG to 300 kcmil Cu/Al
  • Terminals: Load Side
  • Trip Unit: Thermal/Magnetic
  • Certifications: UL 489
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

  • Part Number: CCV2200X
  • Manufacturer : Cutler Hammer
  • Brand : Cutler Hammer
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : Tenant Main
  • Type : CCV
  • Voltage : 240
  • Amperage : 200
  • Phase : 1
  • Poles : 2
  • AIC rating : 10kA@240V
  • Connection : Bolt-On
  • Functions : LI - Long-Time and Instantaneous
  • Protection : Thermal Magnetic

Product Data

  • UPC : 786685368580
  • GTIN : 00786685368580
  • Country of Origin : Dominican Republic
  • Dimensions : 8 in x 5.5 in x 4.5 in (Length/Depth x Height x Width)
  • Weight : 2.83 lb
  • Certification : UL 489
