C25ENF440T - Cutler Hammer 40A 600V 4 Pole Definite Purpose Contactor with 24V AC Coil

C25ENF440T

C25ENF440T is a Cutler Hammer definite purpose contactor rated for 40 amps and 600 volts with a 4 pole configuration and a 24 volt AC coil.This contactor features a non-reversing design with quick connect terminals and a metal mounting plate. It is suitable for HVAC, refrigeration, and motor control applications requiring reliable switching of inductive and resistive loads. The C25ENF440T is UL recognized, CSA certified, and RoHS compliant, ensuring safety and environmental standards.

• Amperage Rating: 40A inductive, 50A resistive
• Voltage Rating: 600V AC maximum
• Number of Poles: 4
• Coil Voltage: 24V AC, 50/60 Hz
• Mounting Type: Open with metal mounting plate
• Terminals: Box lugs with posidrive setscrew and quick connect side-by-side
• Type: Non-reversing definite purpose contactor
• Interrupt Rating: Suitable for HVAC and motor control loads
• Certifications: UL recognized, CSA certified, RoHS compliant
• Frame/Series: C25 Series

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This Definite Purpose Contactor includes a 24 VAC coil.

Specifications

• Part Number: C25ENF440T
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : C25 Series
• Type : C25
• Voltage : 600
• Amperage : 40
• Phase : 3
• Poles : 4
• Temp Rating : -13–158 °F (-25–70 °C)
• Configuration : Non-Reversing
• Coil Voltage Maximum : 24
• Coil Voltage Minimum : 24
• Frequency : 50 Hz

Product Data

• UPC : 782113536613
• GTIN : 00782113536613
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 3.75 in x 2.68 in (Length/Depth x Height x Width)
• Weight : 2.3 lb
• Temp Rating : -13–158 °F (-25–70 °C)
• Certification : CSA Certified,UL Recognized,RoHS Compliant
