C25ENF440C - Cutler Hammer 40A 440-480VAC 4 Pole Definite Purpose Contactor, Open Frame, Quick Connect Terminals

C25ENF440C

C25ENF440C is a Cutler Hammer definite purpose contactor rated for 40 amps with a 440-480 VAC coil and 4 poles designed for reliable motor control applications. C25ENF440C features an open enclosure with a metal mounting plate, quick connect and box lug terminals, and is non-reversing. It is suitable for HVAC, lighting, and other industrial equipment requiring a compact, efficient contactor with CSA and UL certifications.

• Amperage Rating: 40A inductive, 50A resistive
• Coil Voltage: 440-480 VAC, 50/60 Hz
• Number of Poles: 4 (4NO)
• Mounting: Open frame with metal mounting plate
• Terminals: Box lug (posidrive setscrew) and quick connect side-by-side
• Interrupt Rating: Suitable for definite purpose applications
• Frame Size: E-frame, 15-50A range
• Type: Non-reversing
• Certifications: UL Recognized, CSA Certified, RoHS Compliant
• Weight: Approx. 2.1 lbs
• Warranty: 1 year

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This Definite Purpose Contactor includes a 440 VAC coil.

Specifications

• Part Number: C25ENF440C
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : C25 Series
• Type : C25
• Voltage : 600
• Amperage : 40
• Phase : 3
• Poles : 4
• Temp Rating : -13–158 °F (-25–70 °C)
• Configuration : Non-Reversing
• Coil Voltage Maximum : 480
• Coil Voltage Minimum : 440
• Frequency : 50 Hz

Product Data

• UPC : 782113556741
• GTIN : 00782113556741
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 3.75 in x 2.68 in (Length/Depth x Height x Width)
• Weight : 2.11 lb
• Temp Rating : -13–158 °F (-25–70 °C)
• Certification : CSA Certified,UL Recognized,RoHS Compliant
