C25ANB130A - Cutler Hammer C25 Series 30A 1-Pole 600V Non-Reversing Contactor with 120V Coil

C25ANB130A

C25ANB130A is a Cutler Hammer C25 Series definite purpose contactor designed for reliable motor control applications. This single-pole, non-reversing contactor features a 120V AC coil and is rated for 30A at 600V, making it suitable for a wide range of industrial and commercial uses. The C25ANB130A contactor is built with an open enclosure and includes a metal mounting plate for secure installation. It supports both binding head screw and quick connect terminals for flexible wiring options. This compact contactor is engineered for durability and efficient operation in demanding environments.

• Part Number: C25ANB130A
• Manufacturer: Cutler Hammer
• Series: C25
• Amperage Rating: 30A
• Maximum Voltage: 600V
• Number of Poles: 1
• Coil Voltage: 110-120V AC, 50/60 Hz
• Mounting Type: Metal mounting plate
• Enclosure Type: Open
• Terminal Type: Binding head screw and quick connect
• Application: Motor control
• Operating Temperature: -13 to 158°F

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This Definite Purpose Contactor includes a 24 VAC coil.

Specifications

• Part Number: C25ANB130A
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : C25 Series
• Type : C25
• Voltage : 600
• Amperage : 30
• Phase : 1
• Poles : 1
• Configuration : Non-Reversing
• Coil Voltage Maximum : 120
• Full Load Amps : Full Load Amps-Inductive 30A Full Load Amps-Resistive 40A
• Coil Voltage Minimum : 120
• Frequency : 50 Hz

Product Data

• UPC : 786685115856
• GTIN : 00786685115856
• Country of Origin : China
• Dimensions : 2.32 in x 3.19 in x 1.97 in (Length/Depth x Height x Width)
• Weight : 0.5 lb
• Certification : CSA, RoHS, UL Listed
