BRX2110 - Cutler Hammer Eaton BR Series 110A 2-Pole 120/240V Thermal Magnetic Molded Case Circuit Breaker, 65 kAIC, Plug-In Mount

BRX2110

BRX2110 is a Cutler Hammer Eaton BR Series thermal magnetic molded case circuit breaker designed for reliable circuit protection in commercial and industrial applications.

This two-pole breaker features a 110A amperage rating, 120/240V voltage rating, and a 65 kAIC interrupting capacity. It is UL Listed (file E7819) and meets Federal Specifications Classification W-C375. The plug-in mounting type ensures easy installation, and the thermal-magnetic trip unit provides both overload and short-circuit protection. Suitable for use with #14-2/0 AWG wire sizes and rated for 50-60 Hz systems.

Key Specifications
• Part Number: BRX2110
• Manufacturer: Cutler Hammer Eaton
• Amperage: 110A
• Voltage: 120/240V
• Poles: 2
• Mounting Type: Plug-In
• Interrupt Rating: 65 kAIC
• Series/Frame: BR Series, Molded Case
• Trip Unit: Thermal-Magnetic, Common Trip
• Wire Size: #14-2/0 AWG
• Frequency: 50-60 Hz
• Certifications: UL Listed (E7819), Federal Spec W-C375

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BRX2110
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BR Series
• Type : BRX
• Voltage : 240
• Amperage : 110
• Phase : 1
• Poles : 2
• AIC rating : 65kA@240V
• Connection : Plug-In
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786685926810
• GTIN : 00786685926810
• Country of Origin : Dominican Republic
• Dimensions : 3 in x 3 in x 2 in (Length/Depth x Height x Width)
• Weight : 0.5
• Certification : UL Listed file E7819,Federal Specifications Classification W-C375
• Wire Size : AWG 14 to AWG 2/0
