BR245ST - Cutler Hammer 45A 240V 2-Pole Plug-In Circuit Breaker with Shunt Trip 10kAIC

BR245ST

BR245ST is a Cutler Hammer 2-pole, 45 amp, 240 Volt plug-in circuit breaker with shunt trip and 10kA interrupt rating.BR245ST features thermal magnetic trip units with common breaker trip, designed for Type BR loadcenters. It supports wire sizes #14-4 AWG copper or aluminum and meets UL 489 and Federal Specification W-C375 certifications.

Key Specifications
• Amperage: 45A
• Voltage: 120/240V
• Poles: 2
• Interrupt Rating: 10kA at 240V
• Mounting Type: 1-Inch Plug-On
• Trip Unit: Thermal Magnetic with Shunt Trip
• Wire Size: #14-4 AWG Cu/Al
• Series/Frame: BR Series
• Certifications: UL 489, Federal Specification W-C375
• Common Breaker Trip
• Weight: Approximately 1 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 120V shunt trip

Specifications

• Part Number: BR245ST
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BR Series
• Type : BR
• Voltage : 240
• Amperage : 45
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Plug-In
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786676000338
• GTIN : 00786676000338
• Country of Origin : Dominican Republic
• Dimensions : 3.25 in x 3 in x 3 in (Length/Depth x Height x Width)
• Weight : 1
• Certification : UL 489,Federal Specifications Classification W-C375
• Wire Size : AWG 14 to AWG 4, Cu/Al
