BR225ST - Cutler Hammer 25A 240V 2-Pole Thermal Magnetic Circuit Breaker Plug-In Type BR

BR225ST

BR225ST is a Cutler Hammer 2-pole, 25 amp, 240 Volt thermal magnetic circuit breaker with plug-in mounting designed for Type BR load centers.

This circuit breaker features a 10 kA interrupting rating at 240V, common trip, and supports wire sizes from 14 to 4 AWG. It is UL listed and compatible with Westinghouse, Challenger, and Bryant panels. The breaker uses a magnetic thermal trip unit and is rated for 50/60 Hz operation.

Key Specifications
• Amperage: 25 A
• Voltage: 120/240 V
• Poles: 2
• Mounting Type: Plug-in
• Interrupt Rating: 10 kA at 240 V
• Series/Frame: Type BR
• Trip Unit: Thermal Magnetic
• Wire Size Range: 14 to 4 AWG
• Common Trip
• UL Listed
• Compatible with Westinghouse, Challenger, Bryant

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 120V shunt trip

Specifications

• Part Number: BR225ST
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BR Series
• Type : BR
• Voltage : 240
• Amperage : 25
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Plug-In
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786676000307
• GTIN : 00786676000307
• Country of Origin : Dominican Republic
• Dimensions : 4.5 in x 3.5 in x 4.5 in (Length/Depth x Height x Width)
• Weight : 0.92
• Certification : UL 489,Federal Specifications Classification W-C375
• Wire Size : AWG 14 to AWG 4, Cu/Al
