BR220ST - Eaton 20A 2-Pole 120/240V Thermal Magnetic Circuit Breaker with Shunt Trip, 10kAIC, Type BR Frame

BR220ST

BR220ST is a 20 amp, 2-pole, 120/240 volt thermal magnetic circuit breaker with a shunt trip, designed for Type BR loadcenters.

This Eaton BR220ST breaker features a 1-inch plug-on mounting type, a 10kA interrupt rating, and a common breaker trip. It supports #14-4 AWG copper/aluminum wiring and complies with UL 489 and Federal Specification W-C375 standards. The breaker is ideal for conventional and renewable energy applications, including marine vessels and data centers.

• Amperage: 20A
• Voltage Rating: 120/240V AC
• Poles: 2
• Mounting Type: 1-inch Plug-On
• Interrupt Rating: 10kAIC
• Frame/Series: Type BR
• Trip Unit: Thermal Magnetic with Shunt Trip
• Wire Range: #14-4 AWG Cu/Al
• Certifications: UL 489, Federal Specification W-C375
• Common Breaker Trip
• Dimensions: 4.5" x 4.25" x 4.0"

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 120V shunt trip

Specifications

• Part Number: BR220ST
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BR Series
• Type : BR
• Voltage : 240
• Amperage : 20
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Plug-In
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786676000291
• GTIN : 00786676000291
• Country of Origin : Dominican Republic
• Dimensions : 4.5 in x 4 in x 4.25 in (Length/Depth x Height x Width)
• Weight : 1
• Certification : UL 489,Federal Specifications Classification W-C375
• Wire Size : #14 to 4 AWG CU/AL
