BQD260 - Siemens 60 Amp 2 Pole 480VAC Molded Case Circuit Breaker, 14kA Interrupt, Panel Mount, Frame 100

BQD260

BQD260 is a Siemens 2 pole molded case circuit breaker rated for 60 amps and 480VAC operation with a 14kA interrupt rating.This Siemens BQD260 circuit breaker features a thermal magnetic trip unit, panel mounting type, and is designed for use in load centers and panelboards. It has a frame size of 100 and supports 277/480 VAC and 125/250 VDC voltages. The breaker provides reliable protection with a 14kA interrupting capacity at 480Y/277V.

Key Specifications
• Amperage: 60 Amps
• Voltage Rating: 480Y/277 VAC, 125/250 VDC
• Number of Poles: 2
• Interrupt Rating: 14 kA
• Mounting Type: Panel Mount
• Frame Size: 100
• Trip Unit: Thermal Magnetic
• Color: Black/Grey
• Frequency: 50/60 Hz
• Phase: Single

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BQD260
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BQD Series
• Type : BQD
• Voltage : 480
• Amperage : 60
• Phase : 1
• Poles : 2
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Lug
• Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
• Breaker Type : Standard
• Protection : Thermal Magnetic

Product Data

• UPC : 783643277298
• GTIN : 00783643277298
• Country of Origin : Mexico
• Dimensions : 2 in x 4.49 in x 4.49 in
• Weight : 1.199
• Panel Type : Siemens P1 Panelboards
• Standards : CSA-C22.2,UL 515
• Certification : CSA-C22.2,UL 515
