2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
BQ3B10000S01
BQ3B10000S01 is a Siemens BQ series molded case circuit breaker with 120V shunt trip.
This 3-pole thermal magnetic circuit breaker features bolt-on mounting, 100A rating, and 240VAC maximum voltage with 10kA interrupting capacity at 240V.
Key Specifications
- Amperage: 100A
- Voltage: 240VAC
- Poles: 3
- Mounting Type: Bolt-On
- Interrupt Rating: 10kA at 240V
- Series/Frame: BQ
- Trip Unit: Thermal Magnetic with 120V Shunt Trip
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Additional Information
complete with non-interchangeable 120V shunt trip
Specifications
- Part Number: BQ3B10000S01
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : BQ Series
- Type : BQ
- Voltage : 240
- Amperage : 100
- Phase : 3
- Poles : 3
- AIC rating : 10kA@240V
- Connection : Bolt-on
- Functions : LI - Long-Time and Instantaneous
- Terminal Connection : Lug
- Frame Size : 125A/BQ
- Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
- MCM Size : Min. Wire Size 8 AWG Max. Wire Size 4 AWG (Al), 6 AWG (Cu)
- Breaker Type : Shunt Trip
- Protection : Thermal Magnetic
Product Data
- UPC : 783643000858
- GTIN : 00783643000858
- Country of Origin : Mexico
- Dimensions : 2.563 x 4.00 x 3.972 inch
- Weight : 1.323
- Panel Type : Siemens Panelboards
- Standards : HACR Rated, UL Listed
- Certification : CSA, HACR, UL
