BQ3B09000S01 - Siemens 90A 240V 3 Pole Molded Case Circuit Breaker BQ Frame Shunt Trip

BQ3B09000S01

BQ3B09000S01 is a Siemens 3 pole, 90 amp, 240 Volt molded case circuit breaker with a BQ frame and shunt trip feature.This Siemens circuit breaker features a thermal magnetic trip unit, 10kA interrupt rating at 240V, and common-trip design for reliable protection. It is designed for bolt-on mounting and includes load side lugs. The breaker complies with industry certifications for safety and performance.

Key Specifications
• Amperage: 90 Amps
• Voltage: 240 Volts AC
• Poles: 3
• Mounting Type: Bolt-on
• Interrupt Rating: 10kA at 240V
• Frame/Series: BQ
• Trip Unit: Thermal Magnetic with Shunt Trip
• Common-Trip Design
• Load Side Lugs Included
• Industry Certifications Compliant

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BQ3B09000S01
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BQ Series
• Type : BQ
• Voltage : 240
• Amperage : 90
• Phase : 3
• Poles : 3
• AIC rating : 10kA@240V
• Connection : Bolt-on
• Functions : Long Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : 125A/BQ
• Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
• MCM Size : Min. Wire Size 8 AWG Max. Wire Size 4 AWG (Al), 6 AWG (Cu)
• Breaker Type : Shunt Trip
• Protection : Thermal Magnetic

Product Data

• UPC : 783643237902
• GTIN : 00783643237902
• Country of Origin : Mexico
• Dimensions : 4.724 x 3.937 x 3.937 inch
• Weight : 1.587
• Panel Type : Siemens Panelboards
• Standards : HACR Rated, UL Listed
• Certification : CSA, HACR, UL
• Wire Size : 2 AWG (Al), 4 AWG (Cu) Min, 1/0 AWG Max
