BQ3B05000S01 - Siemens 50 Amp 3 Pole 240V Bolt-On Molded Case Circuit Breaker, BQ Series, 10kA Interrupt, Thermal Magnetic Trip

BQ3B05000S01

BQ3B05000S01 is a Siemens 3-pole, 50 amp, 240V molded case circuit breaker designed for reliable low voltage power distribution.

This bolt-on circuit breaker features a thermal magnetic trip unit, 10kA interrupting rating, and is part of the Siemens BQ series. It is engineered for durability and safety in commercial and industrial applications.

Key Specifications
• Part Number: BQ3B05000S01
• Manufacturer: Siemens
• Amperage: 50A
• Voltage: 240VAC
• Poles: 3
• Mounting Type: Bolt-on
• Interrupt Rating: 10kA @ 240V
• Series/Frame: BQ
• Trip Unit: Thermal Magnetic
• Shunt Trip: 120VAC (optional)
• Certifications: Not specified in available data

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with non-interchangeable 120V shunt trip

Specifications

• Part Number: BQ3B05000S01
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BQ Series
• Type : BQ
• Voltage : 240
• Amperage : 50
• Phase : 3
• Poles : 3
• AIC rating : 10kA@240V
• Connection : Bolt-on
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : 125A/BQ
• Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
• MCM Size : Min. Wire Size 8 AWG Max. Wire Size 4 AWG (Al), 6 AWG (Cu)
• Breaker Type : Shunt Trip
• Protection : Thermal Magnetic

Product Data

• UPC : 783643237865
• GTIN : 00783643237865
• Country of Origin : Mexico
• Dimensions : 5.906 x 3.937 x 3.937 inch
• Weight : 1.543
• Panel Type : Siemens Panelboards
• Standards : HACR Rated, UL Listed
• Certification : CSA, HACR, UL
