BQ3B050 - Siemens 50 Amp 3 Pole 240V BQ Series Molded Case Circuit Breaker

BQ3B050

This Siemens BQ Series breaker offers a common-trip design with a 10 kA interrupt rating and includes load side lugs for easy installation. It is a bolt-on type breaker suitable for general purpose low voltage circuit protection with UL certification.

Key Specifications
• Amperage: 50 Amps
• Voltage Rating: 240 Volts
• Poles: 3 Pole
• Mounting Type: Bolt-On
• Interrupt Rating: 10 kA
• Series/Frame: BQ Series
• Trip Unit: Thermal Magnetic
• Certifications: UL Listed
• Load Side Lugs Included

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: BQ3B050
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BQ Series
• Type : BQ
• Voltage : 240
• Amperage : 50
• Phase : 3
• Poles : 3
• AIC rating : 10kA@240V
• Connection : Bolt-on
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Lug
• Frame Size : 125A/BQ
• Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
• MCM Size : Min. Wire Size 2 AWG (Al), 4 AWG (Cu) Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic



Product Data

• UPC : 783643102620
• GTIN : 00783643102620
• Country of Origin : Mexico
• Dimensions : 2.756 x 2.756 x 2.756 inch
• Weight : 0.948
• Panel Type : Siemens Panelboards
• Standards : HACR Rated, UL Listed
• Certification : CSA, HACR, UL
