BQ225230 - Cutler Hammer 30A 240V 2-Pole Thermal Magnetic Circuit Breaker Type BQ 10kAIC

BQ225230

BQ225230 is a Cutler Hammer 2-pole, 30 amp, 240 volt thermal magnetic circuit breaker designed for reliable protection in electrical systems.

This Type BQ 1-inch CTL plug-on breaker features a 10kA interrupt rating at 240V, thermal magnetic trip unit, and a rejection tab for secure mounting. It supports quadplex mounting and is HACR rated for HVAC applications. The breaker provides long time and instantaneous trip functions for enhanced circuit protection.

Key Specifications
• Manufacturer: Cutler Hammer
• Part Number: BQ225230
• Amperage: 30A
• Voltage: 240V AC
• Poles: 2
• Interrupt Rating: 10kA at 240V
• Type: BQ Thermal Magnetic
• Mounting: 1-inch CTL Plug-On
• Trip Unit: Thermal Magnetic
• HACR Rated
• Includes Rejection Tab Feature
• Series/Frame: BR

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BQ225230
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BQ Series
• Type : BQ
• Voltage : 240
• Amperage : 30
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Lug
• Protection : Thermal Magnetic

Product Data

• UPC : 786676004510
• GTIN : 00786676000000
• Country of Origin : Dominican Republic
• Dimensions : 3 in x 3 in x 2 in (Length/Depth x Height x Width)
• Weight : 0.9
• Panel Type : Type BR Loadcenters
• Standards : CSA Certified, HACR Rated, UL Listed
• Certification : UL 489,Federal Specifications Classification W-C390
• Wire Size : AWG 14 to AWG 4, Cu/Al
