BPHMCPS100R3C - Eaton 100A 3-Pole Motor Circuit Protector, 600VAC, F Frame

BPHMCPS100R3C

BPHMCPS100R3C is a 100 amp, 3-pole motor circuit protector from Eaton designed for panel mounting and motor circuit protection.BPHMCPS100R3C features a molded case construction with magnetic-only trip, suitable for 600 VAC and 250 VDC systems. It has a fixed instantaneous trip range of 300 to 1000 amps, Frame F size, and is UL and CSA certified. This motor circuit protector is designed for use with motor starters equipped with electronic overload relays and includes non-aluminum line and load side lug terminals.

Key Specifications
• Amperage: 100 A
• Voltage: 600 VAC / 250 VDC
• Poles: 3
• Frame: F Frame (JK Frame size)
• Trip Type: Magnetic only, fixed instantaneous trip 300-1000 A
• Mounting Type: Panel mount
• Certifications: UL Listed, CSA Certified
• Terminal Material: Non-aluminum
• Motor FLA Range: 23.0 to 84.5 A
• Interrupt Rating: 65 kA at 480 V

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BPHMCPS100R3C
• Manufacturer : Eaton
• Category : Bus Plug
• Item Subcategory : Breaker Type
• Family : Standard Design
• Type : BPHMCPS
• Voltage : 600
• Amperage : 100
• Phase : 3
• AIC rating : 65kA@480V
• Wire : 3
• Compatible Frames : HMCPS

Product Data

• Weight : 40
