Product Info
- Manufacturer:Eaton
- Sub-Category:Breaker Type
Description
BPHFD
BPHFD is a 50 Amp, 600 Volt, 3-pole breaker type bus plug from Eaton designed for Pow-R-Way busway systems.This bus plug features an HFD circuit breaker frame and is suitable for use in three-phase, four-wire busway applications. It provides reliable plug-in connection for power distribution with a 100% neutral option and complies with NEMA standards. The unit is CSA certified and UL 857 and IEEE certified for safety and performance.
- Amperage Rating: 50 Amps
- Voltage Rating: 600 Volts
- Number of Poles: 3
- Circuit Breaker Frame: HFD
- Application: Busway
- Design: Pow-R-Way
- Neutral: 100%
- Certifications: CSA, UL 857, IEEE
- Mounting Type: Plug-in
Specifications
- Part Number: BPHFD
- Manufacturer : Eaton
- Category : Bus Plug
- Item Subcategory : Breaker Type
- Family : Standard Design
- Type : BPHFD
- Voltage : 600
- Amperage : 225
- Phase : 3
- AIC rating : 65kA@480V
- Wire : 3
- Compatible Frames : HFD
Product Data
- Weight : 40
