Product Info
- Manufacturer:Gould
- Sub-Category:Fusible
Description
BOS14354
BOS14354 is a 200 amp, 600 volt, 3-pole fusible bus plug from Gould's BD Series designed for plug-in bus duct systems.This bus plug features a 3-phase, 3-wire configuration with a fusible design suitable for overcurrent protection using R-class fuses. It supports a maximum horsepower rating of 150 HP (time delay) and 60 HP standard per NEC. The unit includes 250 MCM mechanical lugs and is floor-operable, providing reliable power distribution and protection in industrial and commercial applications.
- Key Specifications
- Amperage: 200 Amps
- Voltage: 600 VAC
- Poles: 3
- Wires: 3
- Series/Frame: BD Series (Bulldog)
- Fuse Type: Fusible, R-class standard
- Interrupt Rating: 65kA at 480V
- Horsepower Rating: 60 HP standard, 150 HP max (time delay)
- Mounting Type: Plug-in busway
- Mechanical Lugs: 250 MCM standard
- Certifications: NEC compliant
- Part Number: BOS14354
- Manufacturer : Gould
- Brand : Siemens
- Category : Bus Plug
- Item Subcategory : Fusible
- Family : BD Series
- Type : BOS
- Voltage : 600 AC
- Amperage : 200
- Phase : 3
- AIC rating : 65kA@480V
- Fuse Class : R,H,K
- Wire : 3
- UPC : 783643700420
- GTIN : 00783643700420
- Country of Origin : Mexico
- Dimensions : 21.654 x 11.811 x 12.598 inch
- Weight : 30.468
- Certification : UL Listed
