Description
BOS14321G
BOS14321G is a Siemens Bulldog-type fusible bus plug designed for use on Siemens BD series plug-in busway systems. This 3-phase, 3-wire bus plug provides reliable power distribution with a 30-ampere rating at 240 volts and a maximum voltage rating of 250 volts AC/DC. The fusible design offers overcurrent protection and is compatible with BD plug-in bus duct installations.The BOS14321G features a robust BOS frame type construction suitable for industrial and commercial electrical applications. With a standard interrupting rating of 65 kiloamperes at 240 volts, this bus plug meets industry standards for short-circuit protection. The unit supports a standard horsepower rating of 3 HP under NEC guidelines, with a maximum time-delay rating of 7.5 HP. This bus plug is ideal for applications requiring secure, efficient power connections in busway systems.
- Amperage Rating: 30 Amps
- Voltage Rating: 240V (Maximum 250V AC/DC)
- Phase Configuration: 3-Phase, 3-Wire
- Frame Type: BOS (Bulldog)
- Mounting: BD Series Plug-In Busway Compatible
- Interrupting Rating: 65 kA at 240V
- Fuse Type: Fusible
- Standard Horsepower: 3 HP
- Maximum Time-Delay Horsepower: 7.5 HP
- Manufacturer: Siemens
Specifications
- Part Number: BOS14321G
- Manufacturer : Siemens
- Brand : Siemens
- Category : Bus Plug
- Item Subcategory : Fusible
- Family : BD Series
- Type : BOS
- Voltage : 240
- Amperage : 30
- Phase : 3
- AIC rating : 65kA@240V
- Fuse Class : R,H,K
- Wire : 3
Product Data
- Weight : 35
