2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
BABRP1030
BABRP1030 is a Westinghouse 30 Amp, single-pole, 120 Volt bolt-on circuit breaker designed for reliable electrical protection.This circuit breaker features a bolt-on mounting type and is rated for 30 amps continuous current at 40¡C. It is UL 489 and CSA certified, ensuring compliance with safety standards. The breaker is part of the BAB series and provides thermal-magnetic trip protection suitable for panelboards requiring a 1-pole, 120V breaker.
- Key Specifications
- Amperage: 30 A
- Voltage: 120 V
- Poles: 1
- Mounting Type: Bolt-On
- Series/Frame: BAB
- Trip Unit: Thermal-Magnetic
- Certifications: UL 489, CSA Std. C22.2
- Interrupt Rating: 10,000 AIC (typical for BAB series)
- Dimensions: Approx. 6.25 in depth, 3.75 in height, 1.25 in width
- Weight: 0.54 lb
- Part Number: BABRP1030
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Quicklag
- Type : BABR
- Voltage : 120
- Amperage : 30
- Phase : 1
- Poles : 1
- AIC rating : 10kA@120V
- Connection : Bolt-On
- Functions : Long Time and Instantaneous Trip
- Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
- Protection : Thermal Magnetic
- UPC : 782116062324
- GTIN : 00782116062324
- Country of Origin : Dominican Republic
- Dimensions : 6.25 in x 3.75 in x 1.25 in (Length/Depth x Height x Width)
- Weight : 0.54
- Standards : HACR rated
- Certification : UL Listed,CSA Certified
Additional Information
Remotely Operated
