B315HH00S01 - Siemens 15A 120/240V 3 Pole Miniature Circuit Breaker Shunt Trip

B315HH00S01

B315HH00S01 is a Siemens 15 amp, 120/240 volt, 3 pole miniature circuit breaker with shunt trip functionality.

This Siemens B series circuit breaker features a bolt-on mounting type and provides thermal magnetic protection. It is designed for three-phase applications with a 65kA interrupt rating at 240V AC, ensuring reliable circuit protection. The breaker includes a toggle actuator and is part of the HBL frame series.

Key Specifications
• Amperage: 15 A
• Voltage Rating: 120/240 V AC
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 65kA at 240V AC
• Series/Frame: B Series, HBL Frame
• Trip Unit: Shunt Trip
• Actuator Type: Toggle

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 120V shunt trip

Specifications

• Part Number: B315HH00S01
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BL Series
• Type : HBL
• Voltage : 240
• Amperage : 15
• Phase : 3
• Poles : 3
• AIC rating : 65kA@240V
• Connection : Bolt-on
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : 125A/BL
• MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 6 AWG
• Breaker Type : Shunt Trip
• Protection : Thermal Magnetic

Product Data

• UPC : 783643269316
• GTIN : 00783643269316
• Country of Origin : Mexico
• Dimensions : 5.906 x 3.937 x 3.937 inch
• Weight : 1.499
• Panel Type : Siemens P1 Panelboards
• Standards : CSA Certified, HACR Rated, NOM Certified, UL Listed
• Certification : CSA Certified, HACR Rated, NOM Certified, UL Listed
