ANN-325 - Eaton Bussmann Series ANN 325A 125VAC Very Fast-Acting Circuit Limiter Fuse

ANN-325

ANN-325 is a Bussmann Series ANN very fast-acting circuit limiter fuse rated for 325 amperes and 125 volts AC. It is designed for low voltage applications requiring rapid response to short-circuit currents.ANN-325 features a stud mounting style with blade end connections and provides an interrupting rating of 2,500 amps AC at 125 VAC and 2,700 amps DC at 80 VDC. The fuse element is visible through a mica window for easy inspection. It is UL Recognized and CSA accepted for amperages 35-400A and 500A DC only.

Key Specifications
• Amperage: 325 A
• Voltage Rating: 125 VAC, 80 VDC
• Interrupting Rating: 2,500 A AC, 2,700 A DC
• Mounting Type: Stud mount
• Connection Type: Blade end x blade end
• Fuse Type: Very fast-acting circuit limiter
• Series/Frame: Bussmann ANN Series
• Certifications: UL Recognized, CSA accepted
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: ANN-325
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Circuit Breaker
• Item Subcategory : Parts & Accessories
• Section : Limiters
• Family : ANN Series
• Type : ANN



Product Data

• UPC : 051712706452
• GTIN : 00051712706452
• Country of Origin : Mexico
• Dimensions : 3.38 in x 1.62 in x 0.95 in (Length/Depth x Height x Width)
• Weight : 0.27
• Certification : CE, CSA Certification Class 1422-30, UL Guide JFHR2
