Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
3VA5222-5EC61-0AA0
3VA5222-5EC61-0AA0 is a Siemens 2-pole molded case circuit breaker rated for 225 amps and 600 volts with a 35kA interrupt rating at 480V.This Siemens 3VA5 series circuit breaker features UL Frame 250, line protection with TM230 trip unit, and overload protection rated at 225 amps. It is designed for feed-thru connection and DIN rail mounting, suitable for industrial power distribution applications requiring high interrupt capacity and reliable protection.
- Key Specifications
- Amperage: 225 A
- Voltage Rating: 600 V AC
- Poles: 2
- Interrupt Rating: 35 kA at 480 V
- Series/Frame: 3VA5 UL Frame 250
- Trip Unit: TM230
- Mounting Type: DIN Rail
- Connection Type: Feed-Thru
- Overload Protection: 225 A
- Certifications: UL Listed
Specifications
- Part Number: 3VA5222-5EC61-0AA0
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : 3VA
- Voltage : 600
- Amperage : 225
- Phase : 1
- Poles : 2
- AIC rating : 35kA@480V
- Connection : Feed-Thru
- Functions : Long Time and Instantaneous Trip
- Temp Rating : -13¡F-158¡F (-25¡C-70¡C)
- Protection : Thermal Magnetic
Product Data
- UPC : 804766308291
- Weight : 4 lb
- Standards : UL Listed
- Certification : UL Listed
