Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
3VA5220-5EC31-0AA0
3VA5220-5EC31-0AA0 is a Siemens 3-pole molded case circuit breaker designed for reliable circuit protection with a 200 amp rating.This Siemens 3VA5 series breaker features a 200A current rating, 600 VAC voltage rating, and a 35 kA interrupting capacity at 480V. It includes a thermal magnetic trip unit with long-time and instantaneous functions (LI), fixed mounting type, and an IP40 enclosure rating. The breaker supports feed-thru connections and complies with UL and IEC standards.
- Key Specifications
- Amperage: 200 A
- Voltage: 600 VAC
- Number of Poles: 3
- Interrupt Rating: 35 kA @ 480 V
- Trip Unit: Thermal Magnetic (LI functions)
- Mounting Type: Fixed
- Series/Frame: 3VA5
- Enclosure Type: IP40
- Frequency: 50/60 Hz
- Connection Type: Feed-Thru
- Certifications: UL, IEC
- Operating Temperature: -25 to 70 ¡C
Specifications
- Part Number: 3VA5220-5EC31-0AA0
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : 3VA
- Voltage : 600
- Amperage : 200
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Feed-Thru
- Functions : LI - Long Time and Instantaneous
- Temp Rating : -13¡F-158¡F (-25¡C-70¡C)
- Protection : Thermal Magnetic
Product Data
- UPC : 804766308369
- GTIN : 00804766308369
- Weight : 2 lb
- Standards : UL Listed
- Certification : UL Listed
