3VA5212-6ED61-0AA0 - Siemens 125A 480V 2-Pole Circuit Breaker 3VA5 UL Frame 250 65kA Interrupt Rating TM210 Trip Unit

3VA5212-6ED61-0AA0

3VA5212-6ED61-0AA0 is a Siemens 3VA5 molded case circuit breaker with UL frame 250, rated at 125A, 2-pole, and class H breaking capacity of 65kA at 480V.

This circuit breaker provides line protection with TM210 thermal-magnetic trip unit (FTFM), fixed overload protection Ir=125A, and fixed short-circuit protection Ii=10xIn. It features rated insulation voltage Ui=800V, max operational voltage Ue=690V AC 50/60Hz, and rated continuous current Iu=125A at 40C. Switching capacity per UL 489 includes 65kA at 480V, with LI protective function.

Key Specifications

• Part Number: 3VA5212-6ED61-0AA0
• Manufacturer: Siemens
• Series/Frame: 3VA5 UL Frame 250
• Number of Poles: 2
• Rated Continuous Current Iu: 125A at 40C
• Max Rated Operational Voltage Ue AC: 690V
• Rated Insulation Voltage Ui: 800V
• Breaking Capacity Class: H
• UL 489 Interrupt Rating at 480V: 65kA
• UL 489 Interrupt Rating at 240V: 100kA
• Trip Unit: TM210 FTFM LI
• Overload Protection Ir: 125A fixed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 3VA5212-6ED61-0AA0
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : 3VA
• Voltage : 600
• Amperage : 125
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : LI - Long Time and Instantaneous
• Temp Rating : -13¡F-158¡F (-25¡C-70¡C)
• Protection : Thermal Magnetic

Product Data

• UPC : 80476630855
• GTIN : 00804766308550
• Weight : 4
• Standards : UL Listed
• Certification : UL Listed
