XTPR050DC1 - Eaton 50A Rotary Single-Pole IEC Motor Control Circuit Breaker Class 10 Trip

XTPR050DC1

XTPR050DC1 is an Eaton IEC motor control UL 1077 industrial miniature circuit breaker designed for motor protection applications.This single-pole rotary circuit breaker features a 50 amp contact rating with Class 10 trip type, suitable for motor overload protection. It includes a rotary ON/OFF handle with lockout provision, visible trip indication, and phase loss sensitivity. The device is DIN rail mountable and complies with UL 508 and CSA Std. C22.2 certifications. It has a compact 55 mm size and provides fixed short-circuit trip at 14 times the maximum overload setting. Ambient temperature compensation meets IEC/EN 60947 and VDE 0660 standards.

Key Specifications
• Amperage Rating: 50A
• Poles: Single-pole
• Trip Type: Class 10
• Mounting Type: DIN rail
• Size: 55 mm
• Type: Rotary
• Certifications: UL 508, CSA Std. C22.2
• Visible trip indication
• Phase loss sensitivity
• Ambient temperature compensation to IEC/EN 60947, VDE 0660
• Fixed short-circuit trip at 14x overload FLA
• Weight: 0.7 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: XTPR050DC1
• Manufacturer : Eaton
• Brand : Eaton
• Category : Motor Control
• Item Subcategory : Motor Control Part And Accessory
• Family : XT Series
• Voltage : 1

Product Data

• UPC : 015081548422
• GTIN : 04015081548422
• Country of Origin : Germany
• Dimensions : 3 in x 2 in x 3 in (Length/Depth x Height x Width)
• Weight : 0.7 lb
• Certification : ATEX Compliant, CE, CSA, UL 508 Group Motor Type E Compliant, UL Listed
