- Manufacturer:Eaton
- Sub-Category:Motor Control Part And Accessory
Description
XTPB025BC1
XTPB025BC1 is a 25 Amp Eaton manual motor protector with pushbutton ON/OFF operation designed for motor control applications.This Eaton motor protector features a Class 10 adjustable bimetallic overload relay with fixed magnetic short-circuit trip, suitable for motors with full load amperage up to 25A. It mounts easily on a standard 35mm DIN rail and includes screw terminals for secure wiring. The device provides thermal magnetic protection with a trip class of 10 seconds or less, making it ideal for reliable motor starting and stopping. Certified to UL 508 and CSA standards, it offers phase loss sensitivity and ambient temperature compensation per IEC/EN 60947.
- Key Specifications
- Amperage Rating: 25A adjustable (20-25A range)
- Poles: 2-pole
- Trip Class: 10 (10 seconds or less)
- Mounting Type: Standard 35mm DIN rail
- Type: Pushbutton ON/OFF manual motor protector
- Terminal Type: Screw terminals
- Interrupt Rating: Fixed magnetic short-circuit trip
- Size/Frame: 45 mm frame
- Certifications: UL 508, CSA Std. C22.2
- Weight: 0.7 lb
- Warranty: 1 year
- Part Number: XTPB025BC1
- Manufacturer : Eaton
- Brand : Eaton
- Category : Motor Control
- Item Subcategory : Motor Control Part And Accessory
- Voltage : 3
- UPC : 015082888934
- GTIN : 04015082888930
- Country of Origin : Germany
- Dimensions : 4 in x 3.75 in x 2 in (Length/Depth x Height x Width)
- Weight : 0.7 lb
- Certification : ATEX Compliant, CE, CSA, UL 508 Group Motor Type E Compliant, UL Listed
