Product Info
- Manufacturer:Eaton, Cutler Hammer
- Sub-Category:Part And Accessory
Description
XTFC010BBA
XTFC010BBA is an Eaton XT IEC Type F full voltage non-reversing combination motor controller designed for reliable motor protection and control in industrial applications. This compact unit integrates a manual motor protector with an IEC contactor to deliver motor disconnect, thermal overload protection, magnetic short-circuit protection, and remote control operation in a single assembled package. Key Specifications
- Amperage Rating: 10A adjustable from 6.3A to 10A
- Coil Voltage: 110/120V AC
- Frequency Rating: 50/60 Hz
- Frame Size: 45 mm, Frame B
- Auxiliary Contact: 1 NO, 1 NC
- Motor Applications: 0.25A rated
- Overload Protection: Class 10
- Operating Temperature: Up to 140 degrees Fahrenheit (55 degrees Celsius)
- Features: Visible trip indication, test trip function, built-in heater and magnetic trip elements, phase loss sensitivity
- Mounting: DIN rail mount
- Coordination: Type 2
- Certification: UL 508
Additional Information
Non-Reversing
Specifications
- Part Number: XTFC010BBA
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Motor Control
- Item Subcategory : Part And Accessory
- Section : Controller
- Family : XT Series
- Type : XTFC
- Amperage : 0.25 Amp
- Aux Contacts : 1 NO + 1 NC
- Coil Voltage Maximum : 110 VAC
- Frequency : 50 Hz
Product Data
- UPC : 782116601011
- GTIN : 00782116601011
- Country of Origin : Germany
- Dimensions : Length .01in Height .01in Width .01in
- Weight : 0.01
- Certification : IEC 60947-4-1,UL Listed file E245398,CE Marked
