XTCE095FS1A - Eaton XT IEC 95A 3-Pole Full Voltage Non-Reversing Contactor

XTCE095FS1A

XTCE095FS1A is an Eaton XT IEC series full voltage non-reversing contactor designed for three-phase motor control applications. This industrial-grade contactor delivers reliable switching performance in demanding environments with its robust construction and proven reliability. XTCE095FS1A features a 95-ampere rating at 600 VAC, making it suitable for controlling motors up to 40 HP at 230V, 50 HP at 460V, and 100-125 HP at higher voltages in three-phase systems. The unit includes a 110/120 VAC coil rated for 50/60 Hz operation and incorporates 1NO-1NC auxiliary contacts for enhanced control flexibility. Mounting is side-mounted on DIN rail or panel surfaces, with a compact Frame F design measuring 90 mm.

• Amperage Rating: 95A
• Voltage: 600 VAC
• Control Coil: 110/120 VAC, 50/60 Hz
• Poles: 3-Pole
• Type: Full Voltage Non-Reversing
• Auxiliary Contacts: 1NO-1NC
• Frame Size: F (90 mm)
• Mounting: Side-Mounted DIN Rail/Panel
• Series: XT IEC
• Weight: 4.895 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This IEC Non-Reversing Contactor includes a 110 VAC coil.

Specifications

• Part Number: XTCE095FS1A
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : XT Series
• Type : XTCE095F
• Voltage : 600
• Amperage : 95
• Phase : 3
• Poles : 3
• Configuration : Non-Reversing
• Aux Contacts : 1 NO + 1 NC
• Coil Voltage Maximum : 120
• Coil Voltage Minimum : 120
• Frequency : 50 Hz

Product Data

• UPC : 786685365145
• GTIN : 00786685365145
• Country of Origin : United States
• Dimensions : 1 in x 1 in x 1 in (Length/Depth x Height x Width)
• Weight : 1
• Certification : UL Listed,CSA Certified,IEC 60947,EN 60947
