XTCE095F00C - Cutler Hammer 95A 3-Pole Full Voltage Non-Reversing Contactor 480V Frame F XT IEC Series

Save $433.13
SKU: XTCE095F00C-New
Condition: New
Price:
$333.87 $767.00
Stock:
Low inventory, please call for stock check
Factory Lead Time: 69 business days. Ships based on manufacturer availability when out of stock. All factory-ordered products are non-cancelable and non-returnable.

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

XTCE095F00C Cutler Hammer XT Series Contactor 600V 95A 480V Coil - Essential Electric Supply
XTCE095F00C Cutler Hammer XT Series Contactor 600V 95A 480V Coil - Essential Electric Supply
XTCE095F00C Cutler Hammer XT Series Contactor 600V 95A 480V Coil - Essential Electric Supply
XTCE095F00C Cutler Hammer XT Series Contactor 600V 95A 480V Coil - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
XTCE095F00C Cutler Hammer XT Series Contactor 600V 95A 480V Coil - Essential Electric Supply
XTCE095F00C Cutler Hammer XT Series Contactor 600V 95A 480V Coil - Essential Electric Supply
XTCE095F00C Cutler Hammer XT Series Contactor 600V 95A 480V Coil - Essential Electric Supply
XTCE095F00C Cutler Hammer XT Series Contactor 600V 95A 480V Coil - Essential Electric Supply

Description

XTCE095F00C


XTCE095F00C is a Cutler Hammer 95A 3-pole full voltage non-reversing contactor designed for motor control applications.This contactor is part of the XT IEC Series with a Frame F size and 90 mm frame width. It operates at coil voltages of 415-480 VAC, 50/60 Hz, and supports a maximum horsepower rating of up to 125 HP at 575 VAC three-phase. The device features screw terminals and is UL Listed, IEC Rated, CSA Certified, and CE Marked, meeting EN 60947 and IEC 60947 standards.
    Key Specifications
    • Amperage Rating: 95A
    • Voltage Rating: 415-480 VAC, 50/60 Hz
    • Number of Poles: 3 (Three-pole)
    • Frame Size: F (90 mm)
    • Type: Full Voltage Non-Reversing Contactor
    • Horsepower Ratings: 40 HP @ 200 VAC, 50 HP @ 230 VAC, 100 HP @ 460 VAC, 125 HP @ 575 VAC (3 Phase)
    • Contact Configuration: 0 NO, 0 NC auxiliary contacts
    • Terminals: Screw terminals
    • Certifications: UL Listed, IEC Rated, CSA Certified, CE Marked
    At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

    Additional Information

    This IEC Non-Reversing Contactor includes a 415 VAC coil.


    Specifications

    • Part Number: XTCE095F00C
    • Manufacturer : Cutler Hammer
    • Brand : Cutler Hammer
    • Category : Motor Control
    • Item Subcategory : Contactor
    • Family : XT Series
    • Type : XTCE095F
    • Voltage : 600
    • Amperage : 95
    • Phase : 3
    • Poles : 3
    • Horse Power : HP @ 3 Phase - 208V 25 hp HP @ 3 Phase - 240V 40 hp HP @ 3 Phase - 480V 75 hp
    • Configuration : Non-Reversing
    • Aux Contacts : 0 NO + 0 NC
    • Coil Voltage Maximum : 480
    • Full Load Amps : Full Load Amps-Inductive 95A Full Load Amps-Resistive 130A
    • Coil Voltage Minimum : 480
    • Frequency : 50 Hz

    Product Data

    • UPC : 782116486939
    • GTIN : 00782116486939
    • Country of Origin : Germany
    • Dimensions : 5.59 in x 6.69 in x 3.54 in (Length/Depth x Height x Width)
    • Weight : 2 lb
    • Certification : CE, CSA, EN 60947, IEC 60947, IEC Rated, UL Listed
