XTCE095F00A - Eaton 95A 3-Pole IEC Non-Reversing Motor Contactor, 110/120V Coil, Frame F, 75 HP at 460V

Save $308.02
SKU: XTCE095F00A-New
Condition: New
Price:
$389.98 $698.00
Stock:
8 In stock, ready to be shipped

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

XTCE095F00A - Essential Electric Supply
XTCE095F00A Eaton XT IEC Contactor - Essential Electric Supply
XTCE095F00A - Eaton 95A 3-Pole IEC Non-Reversing Motor Contactor, 110/120V Coil, Frame F, 75 HP at 460V - Essential Electric Supply
XTCE095F00A - Eaton 95A 3-Pole IEC Non-Reversing Motor Contactor, 110/120V Coil, Frame F, 75 HP at 460V - Essential Electric Supply
XTCE095F00A - Eaton 95A 3-Pole IEC Non-Reversing Motor Contactor, 110/120V Coil, Frame F, 75 HP at 460V - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
XTCE095F00A - Essential Electric Supply
XTCE095F00A Eaton XT IEC Contactor - Essential Electric Supply
XTCE095F00A - Eaton 95A 3-Pole IEC Non-Reversing Motor Contactor, 110/120V Coil, Frame F, 75 HP at 460V - Essential Electric Supply
XTCE095F00A - Eaton 95A 3-Pole IEC Non-Reversing Motor Contactor, 110/120V Coil, Frame F, 75 HP at 460V - Essential Electric Supply
XTCE095F00A - Eaton 95A 3-Pole IEC Non-Reversing Motor Contactor, 110/120V Coil, Frame F, 75 HP at 460V - Essential Electric Supply

Description

XTCE095F00A


XTCE095F00A is a 95 amp, 3-pole IEC non-reversing motor contactor from Eaton designed for motor control applications with a 110/120V AC coil.XTCE095F00A features a Frame F size with screw terminals and supports motor ratings up to 75 HP at 460V and 40 HP at 230V. It operates at 50/60 Hz frequencies and complies with IEC 60947, UL, CSA, and CE certifications. This contactor is suitable for full voltage non-reversing control with a compact 90 mm frame and is rated for continuous 95A current. It offers reliable operation with a coil voltage of 110 Vac at 50 Hz and 120 Vac at 60 Hz.
    Key Specifications
    • Amperage Rating: 95 A
    • Number of Poles: 3 (Three-pole)
    • Coil Voltage: 110 Vac 50 Hz / 120 Vac 60 Hz
    • Horsepower Rating: 40 HP @ 230V, 75 HP @ 460V
    • Frame Size: F (90 mm)
    • Mounting Type: Screw terminals
    • Operation: Full voltage non-reversing
    • Standards: IEC 60947, UL Listed, CSA Certified, CE Marked
    • Contact Configuration: 0 NO, 0 NC auxiliary contacts
    • Frequency Rating: 50-60 Hz
    • Product Weight: 6 lb
    At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

    Additional Information

    This IEC Non-Reversing Contactor includes a 110 VAC coil.


    Specifications

    • Part Number: XTCE095F00A
    • Manufacturer : Cutler Hammer
    • Brand : Cutler Hammer
    • Category : Motor Control
    • Item Subcategory : Contactor
    • Family : XT Series
    • Type : XTCE095F
    • Voltage : 600
    • Amperage : 95
    • Phase : 3
    • Poles : 3
    • Horse Power : HP @ 3 Phase - 208V 25 hp HP @ 3 Phase - 240V 40 hp HP @ 3 Phase - 480V 75 hp
    • Configuration : Non-Reversing
    • Aux Contacts : 0 NO + 0 NC
    • Coil Voltage Maximum : 120
    • Full Load Amps : Full Load Amps-Inductive 95A Full Load Amps-Resistive 130A
    • Coil Voltage Minimum : 120
    • Frequency : 50 Hz

    Product Data

    • UPC : 01508239477
    • GTIN : 04015082394776
    • Country of Origin : Romania
    • Dimensions : 7 in x 4 in x 7 in (Length/Depth x Height x Width)
    • Weight : 6 lb
    • Certification : CE, CSA, EN 60947, IEC 60947, RoHS, UL Listed
