XTCE012B10E - Cutler Hammer 12A 3-Pole 208V IEC Contactor XT Series Frame B

XTCE012B10E

XTCE012B10E is a Cutler Hammer XT Series IEC contactor designed for reliable motor control applications. This 3-pole, 12A device features a 208V AC coil and is built for full voltage non-reversing operation. It offers screw terminals and is suitable for panel or DIN rail mounting, making it ideal for a variety of industrial environments. The XTCE012B10E contactor is part of the XT IEC series, known for its robust construction and ease of installation. It is rated for 12A continuous current and features a 208V AC, 60 Hz coil. The device includes one normally open auxiliary contact and is designed for three-phase motor control. Its compact frame size and versatile mounting options make it a practical choice for motor starters and control panels.

• 12A continuous current rating
• 208V AC, 60 Hz coil voltage
• Three-pole configuration
• Full voltage non-reversing type
• Screw terminals
• Panel or DIN rail mounting
• Frame B, 45 mm width
• One normally open auxiliary contact
• IP20 protection rating
• CE marked
• XT IEC series
• Three-phase motor control

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This IEC Non-Reversing Contactor includes a 208 VAC coil.

Specifications

• Part Number: XTCE012B10E
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : XT Series
• Type : XTCE012B
• Voltage : 600
• Amperage : 12
• Phase : 3
• Poles : 3
• Temp Rating : -13–158 °F (-25–70 °C)
• Horse Power : HP @ 3 Phase - 208V 3 hp HP @ 3 Phase - 240V 3 hp HP @ 3 Phase - 480V 10 hp
• Configuration : Non-Reversing
• Aux Contacts : 1 NO
• Coil Voltage Maximum : 208
• Full Load Amps : Full Load Amps-Inductive 12A Full Load Amps-Resistive 22A
• Coil Voltage Minimum : 208
• Compatible Frames : PDG,PDF
• Frequency : 60 Hz

Product Data

• UPC : 001508276824
• GTIN : 04015082768249
• Country of Origin : Romania
• Dimensions : 3 in x 2 in x 3 in (Length/Depth x Height x Width)
• Weight : 0.5 lb
• Temp Rating : -13–158 °F (-25–70 °C)
• Certification : CE, CSA, EN 60947, IEC 60947, RoHS, UL Listed
