XTCE012B01A - Eaton 12 Amp 3 Pole IEC Non-Reversing Contactor 110/120V Coil Frame B

XTCE012B01A

XTCE012B01A is a 3-pole IEC non-reversing contactor from Eaton designed for motor control applications with a 12 Amp AC-3 rating and 110/120 Volt AC coil voltage.This contactor supports motor control up to 10 HP at 460V and 5 HP at 230V, featuring one normally closed (N.C.) auxiliary contact. It is part of Eaton's XT IEC series, known for compact size and compliance with IEC, UL, CSA, CCC, and CE standards. The device can be mounted using screw or DIN rail options, making it versatile for various industrial installations.

• Amperage Rating: 12 Amp AC-3, 20 Amp AC-1
• Coil Voltage: 110/120 Volt AC, 50/60 Hz
• Poles: 3
• Horsepower Rating: 10 HP @ 460V, 5 HP @ 230V
• Auxiliary Contacts: 1 Normally Closed (N.C.)
• Mounting Type: Screw or DIN Rail
• Frame: B (45 mm)
• Standards: IEC 60947, UL Listed, CSA Certified, CE Marked, RoHS Compliant

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This IEC Non-Reversing Contactor includes a 110 VAC coil.

Specifications

• Part Number: XTCE012B01A
• Manufacturer : Eaton
• Brand : Eaton
• Category : Motor Control
• Item Subcategory : Contactor
• Voltage : 1
• Amperage : 12
• Phase : 3
• Poles : 3
• Horse Power : HP @ 3 Phase - 208V 3 hp HP @ 3 Phase - 240V 3 hp HP @ 3 Phase - 480V 10 hp
• Configuration : Non-Reversing
• Aux Contacts : 1 NC
• Coil Voltage Maximum : 120
• Coil Voltage Minimum : 120
• Frequency : 50 Hz

Product Data

• UPC : 015082768625
• GTIN : 04015082768621
• Country of Origin : Romania
• Dimensions : 4.92125984 in x 2.67716535 in x 1.77165354 in (Length/Depth x Height x Width)
• Weight : 0.5
• Certification : CE, CSA, EN 60947, IEC 60947, RoHS, UL Listed
