XTCE009B10BD - Cutler Hammer 9A 3-Pole IEC Non-Reversing Contactor 220 Vdc Coil Frame B

XTCE009B10BD

XTCE009B10BD is a Cutler Hammer 3-pole IEC contactor with a 9 amp continuous rating and a 220 Vdc coil voltage.

This non-reversing contactor from the XT IEC series features screw terminals and a single normally open (1 NO) auxiliary contact. It supports motor control applications with horsepower ratings up to 7.5 hp across various voltages, including 115, 200, 230, 460, and 575 V. The compact Frame B design measures approximately 4.93 x 2.68 x 1.77 inches and is UL Listed and CSA Certified for safety and reliability.

• Amperage Rating: 9 A continuous
• Coil Voltage: 220 Vdc
• Number of Poles: 3
• Contact Configuration: 1 Normally Open (1 NO) auxiliary contact
• Type: Full voltage non-reversing contactor
• Series: XT IEC
• Terminals: Screw terminals
• Horsepower Ratings: 0.5, 1, 1.25/3, 3, 5, 7.5 hp (1/3PH @115, 200, 230/200, 230, 460, 575 V)
• Mounting: Screw or DIN rail compatible
• Certifications: UL Listed, CSA Certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This IEC Non-Reversing Contactor includes a 220 VDC coil.

Specifications

• Part Number: XTCE009B10BD
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : XT Series
• Voltage : 600
• Amperage : 9
• Phase : 3
• Poles : 3
• Configuration : Non-Reversing
• Aux Contacts : 1 NO
• Coil Voltage Maximum : 220
• Coil Voltage Minimum : 220
• Compatible Frames : PDG,PDF

Product Data

• UPC : 001508276709
• Dimensions : 4.92913386 in x 2.67716535 in x 1.77165354 in (Length/Depth x Height x Width)
• Weight : 0.61729433
