XT4HU3150BYJ000XXX - ABB 150A 600VAC 3-Pole Molded Case Circuit Breaker Tmax XT4H Frame

XT4HU3150BYJ000XXX

XT4HU3150BYJ000XXX is a 3-pole, 150 amp molded case circuit breaker from ABB's Tmax XT4H series designed for reliable low voltage protection.This breaker features a 600 VAC voltage rating, 25 kA interrupting capacity at 480 VAC, and a thermal magnetic trip unit. It is UL and CSA certified, with front-connected terminals suitable for industrial and commercial electrical distribution systems. The XT4H frame supports wire sizes from AWG 4 to 300 Cu/Al and offers adjustable trip settings from 750 to 1500 amps.

• Amperage: 150 A
• Voltage Rating: 600 VAC max
• Poles: 3
• Interrupt Rating: 25 kA @ 480 VAC / 18 kA @ 600 VAC
• Frame Type: Tmax XT4H
• Trip Unit: Thermal Magnetic (Adjustable)
• Mounting Type: Front-connected terminals
• Certifications: UL 489, CSA
• Wire Compatibility: AWG 4 to 300 Cu/Al
• Dimensions: Approx. 6.3 in H x 4.13 in W x 3.25 in D

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: XT4HU3150BYJ000XXX
• Manufacturer : ABB
• Brand : ABB
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : SACE Tmax XT
• Type : XT4HU
• Voltage : 600
• Amperage : 150
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Protection : Thermal Magnetic

Product Data

• Country of Origin : United States
• Weight : 8
• Standards : UL, CSA
• Certification : UL, CSA
• Wire Size : AWG 4 to AWG 300, Cu/Al
