V7E2603LR - Siemens Panelboard Switch 100A 600V 2-Pole Visible Blade

V7E2603LR

V7E2603LR is a Siemens panelboard switch designed for reliable load break switching in electrical distribution systems. This visible blade disconnect switch features quick make and break switching action with a robust construction suitable for both main and branch circuit applications.Technical Description

The V7E2603LR is a 2-pole, 100-ampere panelboard switch rated for 600 volts AC operation. It incorporates a visible blade design that provides clear indication of the switch position and enables safe visual confirmation of circuit isolation. The switch is panel-mounted with a compact footprint optimized for installation in electrical enclosures. It meets UL 98 standards and is suitable for motor disconnect and general load break applications.

Key Specifications

• Amperage Rating: 100A
• Voltage Rating: 600V AC
• Number of Poles: 2
• Switch Type: Visible Blade Panelboard Switch
• Mounting: Panel Mount
• Load Break Rated: Yes
• UL 98 Certified: Yes
• Quick Make and Break Action: Yes
• Suitable for Motor Disconnect Applications: Yes

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: V7E2603LR
• Manufacturer : Siemens
• Category : Switch
• Item Subcategory : Panel Mount
• Family : Vacu-Break
• Type : V7E
• Voltage : 600
• Amperage : 100
• Phase : 1
• Poles : 2
• AIC rating : 200kA@480V
• Fuse Class : R,H,K
• Configuration : Single
• Switch Style : Fusible
• Nema Rating : 1
• Compatible Frames : PJP

Product Data

• UPC : 783643232792
• GTIN : 00783643232792
• Weight : 20.834
