Product Info
- Manufacturer:ITE
- Sub-Category:Panel Mount
Description
V7B2222LR
V7B2222LR is a 60 Amp, 240 Volt, 2-pole fusible Vacu-Break panel mount switch from ITE designed for reliable power distribution control.V7B2222LR features a NEMA 1 enclosure rating and a high interrupting capacity of 200kA at 240V, ensuring safe operation in demanding electrical environments. This switch accepts Class RHK fuses and is part of the V7B series, providing robust panelboard switching with left and right side bus connections.
- Amperage: 60 Amps
- Voltage: 240 Volts
- Poles: 2
- Mounting Type: Panel Mount
- Interrupt Rating: 200kA at 240V
- Series/Frame: V7B
- Fuse Type: Class RHK
- Enclosure Type: NEMA 1
Specifications
- Part Number: V7B2222LR
- Manufacturer : ITE
- Brand : Siemens
- Category : Switch
- Item Subcategory : Panel Mount
- Family : Vacu-Break
- Type : V7B
- Voltage : 240
- Amperage : 60
- Phase : 1
- Poles : 2
- AIC rating : 200kA@240V
- Fuse Class : R,H,K
- Configuration : Dual/Twin
- Switch Style : Fusible
- Nema Rating : 1
- Compatible Frames : PJP
Product Data
- UPC : 783643232648
- GTIN : 00783643232648
- Country of Origin : Mexico
- Dimensions : 19.685 x 7.874 x 10.63 inch
- Weight : 14.44
