Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
TMQD22125
TMQD22125 is a General Electric 2 pole thermal magnetic molded case circuit breaker rated for 125 amps and 240 volts AC.This TMQD series breaker features a bolt-on mounting type and provides a 100kA interrupting rating at 240 volts. It is designed for reliable protection in electrical distribution systems, with a thermal magnetic trip unit for overload and short circuit protection. The breaker is UL listed and suitable for single-phase 3-wire applications.
- Amperage: 125 Amps
- Voltage: 240 VAC
- Poles: 2
- Mounting Type: Bolt-On
- Interrupt Rating: 100kA at 240V
- Series/Frame: TMQD
- Trip Unit: Thermal Magnetic
- Phase: Single-Phase
- Certifications: UL Listed
Specifications
- Part Number: TMQD22125
- Manufacturer : General Electric
- Brand : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Meter Mod
- Type : TMQD
- Voltage : 240
- Amperage : 125
- Phase : 1
- Poles : 2
- AIC rating : 100kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous Trip
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 783164194845
- Weight : 2
