Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
TJK426300WL
TJK426300WL is a General Electric 2-pole molded case circuit breaker rated for 300 amperes at 600 volts with an interrupting capacity of 35 kA at 480V. This TJK-type breaker features a 400-ampere frame and includes factory-installed line and load side lug terminals with an interchangeable trip unit for flexible application requirements. Key Specifications
- Part Number: TJK426300WL
- Manufacturer: General Electric
- Type: TJK Molded Case Circuit Breaker
- Amperage Rating: 300 Amps
- Voltage Rating: 600V
- Poles: 2
- Frame Size: 400 Amperes
- Interrupting Rating: 35 kA at 480V
- Trip Unit: Interchangeable
- Terminals: Line and load side lugs included
- UL Listed: File E-11592
- Standards: UL489 Listed
Specifications
- Part Number: TJK426300WL
- Manufacturer : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : J600 Line
- Type : TJK
- Voltage : 600
- Amperage : 300
- Phase : 1
- Poles : 2
- AIC rating : 30kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 078316404988
- GTIN : 00783164049886
- Weight : 17
