Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
TJK426150WL
TJK426150WL is a General Electric 150 Ampere, 2-Pole Molded Case Circuit Breaker designed for reliable electrical protection in industrial and commercial applications.This circuit breaker features a TJK frame with adjustable trip settings, suitable for use at voltages up to 600 VAC and 250 VDC. It offers a high interrupting rating of 200 kiloamperes at 240 VAC, ensuring robust short-circuit protection. The breaker is bolt-on mounted and UL489 listed for safety and performance compliance.
- Key Specifications
- Amperage: 150A
- Voltage Rating: 600 VAC, 250 VDC
- Number of Poles: 2
- Frame/Series: TJK
- Interrupting Rating: 200 kA at 240 VAC
- Mounting Type: Bolt-On
- Trip Unit: Adjustable
- Certification: UL489 Listed
- Part Number: TJK426150WL
- Manufacturer : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : J600 Line
- Type : TJK
- Voltage : 600
- Amperage : 150
- Phase : 1
- Poles : 2
- AIC rating : 30kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
- Weight : 17
