Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
TJD422250WL
TJD422250WL is a 2-pole, 240 volt, 250 ampere rated molded case circuit breaker manufactured by General Electric. This feed-through circuit breaker features thermal magnetic trip protection and is designed for use in power distribution applications requiring reliable overcurrent protection. TJD422250WL delivers an interrupt rating of 22 kA at 240V, making it suitable for standard commercial and industrial electrical systems. The breaker utilizes aluminum and copper line and load lug terminals for secure connections and is part of General Electric's Q-Line frame family.
- Amperage Rating: 250 A
- Voltage: 240 VAC
- Number of Poles: 2
- Interrupt Rating: 22 kA @ 240V
- Trip Type: Thermal Magnetic
- Frame Type: TJD
- Frequency Rating: 50/60 Hz
- Terminal Type: Aluminum/Copper Line/Load Lug
- UL Listed: File E-11592
Specifications
- Part Number: TJD422250WL
- Manufacturer : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Q-Line
- Type : TJD
- Voltage : 240
- Amperage : 250
- Phase : 1
- Poles : 2
- AIC rating : 22kA@240V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 783164049152
- GTIN : 00783164049152
- Weight : 16
