Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
THQD32100ST1
THQD32100ST1 is a 3 pole, 100 amp, 240 volt bolt-on circuit breaker from General Electric's Q-Line series, designed for reliable protection in commercial and industrial applications.This molded case circuit breaker features a factory-installed 120Vac shunt trip for remote operation and is built for use in 240V systems. The THQD32100ST1 is part of the Q-Line family, known for robust thermal magnetic protection and compatibility with a wide range of panelboards.
- Amperage: 100 A
- Voltage: 240 V
- Poles: 3
- Mounting Type: Bolt-On
- Interrupt Rating: 22 kAIC @ 240V
- Series/Frame: Q-Line
- Trip Unit: Thermal Magnetic
- Shunt Trip: 120Vac, factory installed
- UL Listed: Yes
- UL File #: E11592
- Special Markings: HACR
- Wire Range (Cu/Al): (2) 1-300
Specifications
- Part Number: THQD32100ST1
- Manufacturer : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Q-Line
- Type : THQD
- Voltage : 240
- Amperage : 100
- Phase : 3
- Poles : 3
- AIC rating : 22kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- Weight : 3
