Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
THQD22125
THQD22125 is a General Electric Q-Line series molded case circuit breaker rated for 125 amps, 240 volts AC, and 2 poles, designed for reliable protection in commercial and industrial applications. This breaker features a bolt-on mounting style, non-interchangeable trip unit, and line and load side lug terminals. It offers a standard interrupting rating of 22kA at 240V, making it suitable for a wide range of electrical systems. The THQD22125 is built to meet rigorous safety and performance standards for dependable operation.
- Part Number: THQD22125
- Manufacturer: General Electric
- Series/Frame: Q-Line
- Amperage: 125A
- Voltage: 240V AC
- Poles: 2
- Mounting Type: Bolt-On
- Interrupt Rating: 22kA @ 240V
- Terminal Type: Line & Load Lug
- Common Trip: Yes
- Trip Unit: Non-Interchangeable
- Standards: UL Listed, CSA Certified
Specifications
- Part Number: THQD22125
- Manufacturer : General Electric
- Brand : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Q-Line
- Type : THQD
- Voltage : 240
- Amperage : 125
- Phase : 1
- Poles : 2
- AIC rating : 22kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 783164011012
- GTIN : 00783164087819
- Weight : 2
