THJK436400LL
THJK436400LL is a General Electric 3 pole molded case circuit breaker rated for 400 amperes at 600 volts with thermal magnetic protection and interchangeable trip unit. THJK436400LL features bolt-on mounting, line and load side lug terminals, and is suitable for reverse feed applications. This circuit breaker is part of the J600 frame family and provides long-time and instantaneous trip functions with adjustable instantaneous settings. Key Specifications
- Amperage: 400 A
- Voltage: 600 Vac
- Poles: 3
- Phase: 3
- Frame Type: J600
- Mounting: Bolt-On
- Trip Style: Interchangeable
- Trip Function: LI (Long-Time and Instantaneous)
- 480 Vac Interrupting Rating: 30 KAIC
- UL File Number: E11592
- CSA File Number: LR40350
Specifications
- Part Number: THJK436400LL
- Manufacturer : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : J600 Line
- Type : THJK
- Voltage : 600
- Amperage : 400
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 783164234121
- GTIN : 00783164234121
- Weight : 18
