Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
THHQB1120GF
THHQB1120GF is a 1 pole, 20 amp ground fault circuit breaker from General Electric designed for 120/240VAC applications with a THQL frame.This thermal magnetic molded case circuit breaker features a 10kA interrupting rating at 120V, plug-in mounting, and includes long-time and instantaneous trip functions for reliable ground fault protection. It is UL, CSA, and NEMA certified and suitable for use with Power Mark Gold load centers and AQ lighting panels.
- Amperage: 20 Amp
- Voltage: 120/240VAC
- Poles: 1
- Interrupting Rating: 10kA at 120V
- Mounting Type: Plug-In
- Trip Unit: Thermal Magnetic with Long-Time and Instantaneous Trip
- Frame/Series: THQL
- Certifications: UL, CSA, NEMA
- Wire Size Range: 14 to 8 AWG Copper
- Phase: Single
- Protection: Ground Fault
- Dimensions (LxWxH): 2.37 x 4.62 x 3.12 inches
Specifications
- Part Number: THHQB1120GF
- Manufacturer : General Electric
- Brand : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Q-Line
- Type : THHQB
- Voltage : 120
- Amperage : 20
- Phase : 1
- Poles : 1
- AIC rating : 22kA@120V
- Connection : Bolt-On
- Functions : LI - Long Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 783164485516
- GTIN : 40783164485514
- Weight : 1 lb
- Certification : UL
- Wire Size : 14 to 8 AWG, 12 to 8 AWG
