TEYF145 - General Electric 45A 1 Pole 277/480V AC Bolt-On Molded Case Circuit Breaker

SKU: TEYF145-New
Condition: New
Price:
$596.69
Stock:
Low inventory, please call for stock check

💡 ABB / GE Branding Notice

On June 30, 2018, ABB completed the acquisition of GE Industrial Solutions.

As a result of this transition, certain products may be labeled as either ABB or GE depending on the manufacturing date and production batch. In many cases, the product itself remains identical in form, fit, function, and specifications, with only the branding or label differing.

Customers may receive:

  • ABB-branded products
  • GE-branded products
  • Packaging reflecting either brand

Unless otherwise stated, these are considered the same product and are fully interchangeable under the applicable manufacturer specifications.

If you have questions regarding labeling, compatibility, or product identification, please contact our support team prior to ordering.

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

TEYF145 - General Electric Bolt-on Panelboard 277V 45A 1 pole circuit breaker 18kA@277V - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
TEYF145 - General Electric Bolt-on Panelboard 277V 45A 1 pole circuit breaker 18kA@277V - Essential Electric Supply

Description

TEYF145


TEYF145 is a General Electric 45 amp, 1 pole molded case circuit breaker designed for bolt-on mounting in panelboards.

This circuit breaker features a thermal magnetic trip unit with a fixed instantaneous trip, suitable for single-phase applications at 277/480V AC. It has a maximum interrupting rating of 18kA at 277V AC and a DC voltage rating of 125V DC. The breaker uses lug-type terminal connections and is compatible with GE AE lighting panels. It meets CSA and UL standards and fits a 125A/TEY frame size.

    Key Specifications
    • Amperage: 45A
    • Voltage Rating: 277/480V AC
    • Poles: 1
    • Mounting Type: Bolt-On
    • Interrupt Rating: 18kA at 277V AC
    • Trip Type: Thermal Magnetic with Fixed Instantaneous Trip
    • Terminal Connection: Lugs
    • Frame Size: 125A/TEY
    • DC Voltage Rating: 125V DC
    • Standards: CSA, UL
    • Compatible With: GE AE Lighting Panels

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

  • Part Number: TEYF145
  • Manufacturer : General Electric
  • Brand : General Electric
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : TEYF Series
  • Type : TEYF
  • Voltage : 277
  • Amperage : 45
  • Phase : 1
  • Poles : 1
  • AIC rating : 18kA@277V
  • Connection : Bolt-On
  • Functions : LI - Long-Time and Instantaneous
  • Terminal Connection : Lug
  • Frame Size : 125A/TEY
  • MCM Size : Min. Wire Size 14 AWG Max. Wire Size 10 AWG
  • Breaker Type : Standard
  • Protection : Thermal Magnetic
  • Phase Connection : ABC

Product Data

  • GTIN : 00783164388275
  • Country of Origin : United States
  • Dimensions : 1 in x 5-1/4 in
  • Weight : 3
  • Panel Type : GE AE Lighting Panels
  • Standards : CSA, UL
  • Certification : CSA, UL
