TED136YT150
TED136YT150 is a General Electric 3 pole circuit breaker rated for 150 amps and 600 volts, designed for panel mounting in industrial and commercial applications.TED136YT150 features a thermal magnetic trip unit with a non-automatic switch, 18kA interrupting rating at 480V, and feed-thru connection type. It is part of the TED series frame E150 and supports 3-phase power systems.
- Manufacturer: General Electric
- Part Number: TED136YT150
- Amperage: 150 A
- Voltage Rating: 600 V AC
- Number of Poles: 3
- Frame Type: TED (E150)
- Interrupting Rating: 18kA at 480V
- Trip Unit: Thermal Magnetic (Long-Time and Instantaneous)
- Mounting Type: Panel Mount
- Connection Type: Feed-Thru
- Phase: 3
- Protection: Non-Automatic Switch
- Dimensions: 5" H x 5" W x 9" D
Specifications
- Part Number: TED136YT150
- Manufacturer : General Electric
- Brand : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : E150 Line
- Type : TED
- Voltage : 600
- Amperage : 150
- Phase : 3
- Poles : 3
- AIC rating : 18kA@480V
- Connection : Feed-Thru
- Functions : No Overcurrent Protection
- Protection : Non-Automatic
Product Data
- UPC : 783164190946
- GTIN : 00783164190946
- Weight : 3
