Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
TED136150V
TED136150V is a 3 pole molded case circuit breaker from General Electric, designed for reliable protection in industrial and commercial power distribution systems.This TED series breaker features a 150A current rating and a 600V AC voltage rating, with a bolt-in mounting configuration for secure installation. The breaker is equipped with LI (long time and instantaneous) trip functions for effective overload and short-circuit protection. It is rated for use with GE panelboards and meets UL safety standards.
- Part Number: TED136150V
- Manufacturer: General Electric
- Series: TED
- Frame Type: E150
- Amperage: 150A
- Voltage: 600V AC
- Poles: 3
- Mounting Type: Bolt-in
- Interrupting Rating: 18kA @ 480V AC
- Trip Function: LI (Long Time and Instantaneous)
- Certification: UL
Specifications
- Part Number: TED136150V
- Manufacturer : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : E150 Line
- Type : TED
- Voltage : 600
- Amperage : 150
- Phase : 3
- Poles : 3
- AIC rating : 18kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- Weight : 3
