TED136090V - General Electric 90A 3-Pole 600VAC Molded Case Circuit Breaker

SKU: TED136090V-ReCert
Condition: Re-Certified
Price:
$386.50
Stock:
Low inventory, please call for stock check
This ships in 1-2 business days

💡 ABB / GE Branding Notice

On June 30, 2018, ABB completed the acquisition of GE Industrial Solutions.

As a result of this transition, certain products may be labeled as either ABB or GE depending on the manufacturing date and production batch. In many cases, the product itself remains identical in form, fit, function, and specifications, with only the branding or label differing.

Customers may receive:

  • ABB-branded products
  • GE-branded products
  • Packaging reflecting either brand

Unless otherwise stated, these are considered the same product and are fully interchangeable under the applicable manufacturer specifications.

If you have questions regarding labeling, compatibility, or product identification, please contact our support team prior to ordering.

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

TED136090V General Electric Molded Case Circuit Breaker E150 Line 90A 600V - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
TED136090V General Electric Molded Case Circuit Breaker E150 Line 90A 600V - Essential Electric Supply

Description

TED136090V


TED136090V is a General Electric molded case circuit breaker designed for three-phase power distribution applications. This thermal magnetic trip unit device provides reliable overcurrent protection in industrial and commercial electrical systems.General Electric TED136090V features a 90 ampere rating at 600 volts AC with three poles for three-phase circuits. The breaker utilizes a thermal magnetic trip mechanism for both long-time and instantaneous protection. It is part of the E-150 family and includes bolt-on mounting with line and load side lug terminals for secure installation in panelboards and switchgear enclosures. The interrupt rating is 18 kA at 480 volts, providing standard interrupting capacity for typical industrial applications.
  • Amperage: 90 Amps
  • Voltage: 600 VAC
  • Poles: 3
  • Series: E-150 (Type TED)
  • Trip Unit: Thermal Magnetic (Long-Time and Instantaneous)
  • Interrupt Rating: 18 kA @ 480V
  • Mounting: Bolt-On
  • Terminals: Line and Load Side Lugs
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

  • Part Number: TED136090V
  • Manufacturer : General Electric
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : E150 Line
  • Type : TED
  • Voltage : 600
  • Amperage : 90
  • Phase : 3
  • Poles : 3
  • AIC rating : 18kA@480V
  • Connection : Bolt-On
  • Functions : LI - Long-Time and Instantaneous
  • Protection : Thermal Magnetic

Product Data

  • Weight : 3

Accesories

Part Manufacture Sub Category
TEDAS2AB1
TECBAL
TEDMOMA1
