TED136025WL - General Electric 25A 600V 3 Pole TED Frame Molded Case Circuit Breaker, Thermal Magnetic Trip, 14kA Interrupt

Save $300.79
SKU: TED136025WL-New
Condition: New
Price:
$750.21 $1,051.00
Stock:
Low inventory, please call for stock check

💡 ABB / GE Branding Notice

On June 30, 2018, ABB completed the acquisition of GE Industrial Solutions.

As a result of this transition, certain products may be labeled as either ABB or GE depending on the manufacturing date and production batch. In many cases, the product itself remains identical in form, fit, function, and specifications, with only the branding or label differing.

Customers may receive:

  • ABB-branded products
  • GE-branded products
  • Packaging reflecting either brand

Unless otherwise stated, these are considered the same product and are fully interchangeable under the applicable manufacturer specifications.

If you have questions regarding labeling, compatibility, or product identification, please contact our support team prior to ordering.

Same-Day Shipping

Most items ship same-day if ordered by 1:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

TED136025WL - General Electric Feed-Thru 25 Amp 3 Pole Circuit Breaker - Essential Electric Supply
TED136025WL - General Electric 25A 600V 3 Pole TED Frame Molded Case Circuit Breaker, Thermal Magnetic Trip, 14kA Interrupt - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
TED136025WL - General Electric Feed-Thru 25 Amp 3 Pole Circuit Breaker - Essential Electric Supply
TED136025WL - General Electric 25A 600V 3 Pole TED Frame Molded Case Circuit Breaker, Thermal Magnetic Trip, 14kA Interrupt - Essential Electric Supply

Description

TED136025WL


TED136025WL is a General Electric molded case circuit breaker designed for reliable protection in three-phase electrical systems.

This circuit breaker features a thermal magnetic trip unit for both overload and short-circuit protection, with line and load side lug terminals for flexible installation. It is part of the GE TED (Core E) series, offering robust performance for industrial and commercial applications.

    Key Specifications
  • Amperage: 25A
  • Voltage: 600V AC
  • Poles: 3
  • Mounting Type: Bolt-on (Panelboard)
  • Interrupt Rating: 14kA at 600V
  • Series/Frame: TED (Core E)
  • Trip Unit: Thermal Magnetic, Non-Interchangeable
  • Certifications: Not specified in available data
  • Terminals: Line & Load Side Lug
  • Application: Feed-Thru, 3 Phase
  • Trip Functions: Long Time and Instantaneous
  • Temperature Rating: 25A at 40°C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

  • Part Number: TED136025WL
  • Manufacturer : General Electric
  • Brand : General Electric
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : E150 Line
  • Type : TED
  • Voltage : 600
  • Amperage : 25
  • Phase : 3
  • Poles : 3
  • AIC rating : 18kA@480V
  • Connection : Bolt-on Panelboard
  • Functions : LI - Long-Time and Instantaneous Trip
  • Terminal Connection : Line/Load Lug
  • Frame Size : 150A/TED
  • Temp Rating : -13–158 °F (-25–70 °C)
  • MCM Size : Min. Wire Size 4 AWG (Al), 6 AWG (Cu) Max. Wire Size 2 AWG
  • Breaker Type : Standard
  • Protection : Thermal Magnetic
  • Phase Connection : ABC

Product Data

  • UPC : 783164063165
  • GTIN : 00783164063165
  • Country of Origin : United States
  • Dimensions : 4-1/8 in x 6-5/16 in
  • Weight : 3
  • Panel Type : GE Panelboards
  • Standards : CSA Certified, UL Listed
  • Certification : CSA Certified, UL Listed

Accesories

Part Manufacture Sub Category
TEDAS2AB1
TECBAL
TEDMOMA1
